Freeze dryers
৳ 0.00
Model: VD-250R
Brand: TAITEC
(Call for Price 01324742456)
Features
Simple operation
Turn on the power. When the blue button lights up, the unit is ready for use. Pressing the yellow VAC START button will turn on the pump that is connected to the vacuum pump interlocking outlet on the back of the unit, and then vacuuming starts.
Secure cold trap for the sublimated water
Because of the direct cooling system in which water vapor is directly coagulated and collected on the surface of the cooling coil in the trap chamber, the cooling temperature becomes almost the same as the trap temperature.
Trapped water is quickly defrosted by hot gas. When the DEFROST button is pressed, hot gas will flow into the coil of the cold trap, and ice equivalent to the dehumidification capacity can be defrosted in about 30 minutes.
Specifications
| Model | VD-250R |
|---|---|
| Cooling temperature | -45℃ (at no load) (*) |
| Trapping volume | Approx. 500mL/time |
| Volume inside chamber | Approx. 4L (Inner dia. 160 x 205mm) |
| Compressor | 250W |
| Recommended vacuum pump | Oil-sealed Rotary Vacuum pump (Ultimate pressure below 50Pa, Displacement above 100L/min ) |
| Vacuum hose connection port | For outer dia. φ22 mm (Rc 3/8 Thread on inner surface, Convertible to different dia.), a hose with an inner diameter of φ18 mm is basically used. |
| Vacuum release | Leakage port with filter on the side of the body (N2 Gas purge combined use, Hose attachment port, Pisco φ6 mm), automatically released by halting the vacuum pump. |
| Other functions | Hot gas defrosting (thawing in approx. 30 minutes, outlet for the vacuum pump interlocking (Max. 3 sockets, 9 A, with operation switch) |
| Dimensions/Weight | 375(W) x 420(D) x 525(H)mm, Approx. 34kg |
| Power supply | AC100V/6A /Max.15A(Need a step-down transformer) |
| Standard accessories | Table mat × 1 pc |
