Horizontal Laminar Flow Cabinet
Series: LCB-H
Model: LCB-H1100; LCB-H1300; LCB-H1600; LCB-H1900
Brand: Scitek Global
Origin: USA
Horizontal laminar flow cabinet provides a sterile work zone through a purified air that travels in a horizontal, unidirectional stream and leaves main work chamber across the entire open front of the cabinet. 1pcs prefilter laminar flow cabinet is a popular product for labs. Preferred by large laboratories, pharmaceutical manufacturing and other industries, now the best budget laminar flow cabinet for sale at affordable price.
Laminar Flow Cabinet Features:
- Ergonomic control panel location, centered and angled down for an easy reach & viewing.
- Brushed stainless steel work surface is for easy cleaning.
- The non-direct light source design can effectively relieve the operator’s visual fatigue under the condition of ensuring the illumination.
- Intuitive and easy-to-use microprocessor controller with LCD display, graphical and digital display of the operating status of each function, such as filter life, UV life etc.
Reliability:
- Front sliding sash interlock with fan and UV lamp.
- UV sterilization with UV lamp timing function.
- Front sash and side windows are made of UV-resistant tempered glass.
- The host and sockets have independent capacitors to prevent current overload.
- Memory function in case of power-failure.
Convenience:
- HEPA filter and UV life indicators facilitate a timely replacement plan.
- Two side glass windows installed for easy experiment observation.
- Easy-to-change pre-filter installed could extend the HEPA filter’s lifetime.
- Equipped with temperature sensor to show the real temperature during operation.
- Waterproof socket provide convenience for small instruments to be used in the operating area.
Laminar Flow Cabinet Specifications:
| Model | LCB-H1100 | LCB-H1300 | LCB-H1600 | LCB-H1900 | |||
|---|---|---|---|---|---|---|---|
| External Size (WxDxH)(mm) | 1050x805x1950 | 1320x805x1950 | 1625x805x1950 | 1930x805x1950 | |||
| Internal Size (WxDxH)(mm) | 950x490x574 | 1220x490x574 | 1525x490x574 | 1830x490x574 | |||
| Work Surface Height | 750mm | ||||||
| Control System | Display | Microprocessor controller with LCD display, display the operating status of each function | |||||
| Interlock | Front sliding sash interlock with fan and UV lamp | ||||||
| Life Indicator | HEPA filter and UV life indicators facilitate a timely replacement plan | ||||||
| Airflow System | Airflow Velocity | 0.2~0.5 m/s, speed adjustable | |||||
| Air filtration System | Pre-Filter | 1pcs, Polyester fiber,washable | |||||
| HEPA Filter | 1 pcs, Efficiency: > 99.995% at particle size of 0.3μm | ||||||
| Cleanliness Grade | Class 100 (ISO14644.1 Class 5) | ||||||
| Cabinet Construction | Main Body | Electro-Galvanized steel with antimicrobial powder coating | |||||
| Work Surface | 304 Stainless steel | ||||||
| Front Window | Manual sliding sash: 5 mm UV resistant tempered glass with counter-balance system and ergonomic handle | ||||||
| Side window | 5 mm UV resistant tempered glass | ||||||
| Electrical System | UV Lamp | 20W×2 | 30W×1 | 30W×1 | 18W×2 | ||
| With timing function from 0 to 999 minutes, Interlock with front sliding sash. Emission of 253.7 nanometers for best sterilization effect. |
|||||||
| LED Lamp | 6.5W×1 | 9.6W×1 | 9.6W×1 | 6.5W×2 | |||
| Consumption | 160W | 170W | 300W | 310W | |||
| Not include socket loading power consumption | |||||||
| Power Supply | AC220V±10%, 50/60HZ; 110V±10%, 60Hz | ||||||
| Illumination | ≥900Lux | ||||||
| Sound Emission | ≤65dB(A) | ||||||
| Standard Accessory | 1. Base Stand; 2. LED Lamp; 3. UV Lamp; 4. Waterproof Socket×2; 5.Air Velocity Sensor. | ||||||
| Optional Accessory | 1.Gas Tap; 2. IV Bar with Hooks | ||||||
| Gross Weight (kg) | 220 | 260 | 300 | 340 | |||
| Shipping Size (W×D×H)(mm) | 1190x1010x1425 | 1460x1010x1425 | 1765x1010x1425 | 2070x1010x1425 | |||
| Shipping Volume (m³) | 1.7 | 2.3 | 2.55 | 3 | |||
*Assemble in China.*
