5 inch Touch Screen Panel Viscometer for Viscosity Measurement
৳ 765,000.00
Model: ASJ-8ST
Brand: As One Corporation
Origin: Japan
The Touch Panel Viscometer ASJ-8ST is a high-precision digital viscosity meter designed for accurate viscosity measurement in laboratories, research institutes, pharmaceutical industries, food processing, cosmetics, chemical manufacturing, and quality control applications. Manufactured by AS ONE Corporation, Japan, it features a 5-inch touch panel, real-time measurement display, automatic kinematic viscosity conversion by density input, and multiple viscosity unit selection for convenient operation.
With a wide measurement range of 1 to 2,000,000 mPa·s, excellent accuracy, and intuitive touch-screen interface, the ASJ-8ST provides reliable viscosity analysis for various liquid samples.
Applications:
- Pharmaceutical Laboratories
- Chemical Laboratories
- Food & Beverage Industry
- Cosmetics Industry
- Paint & Coating Testing
- Petrochemical Laboratories
- Research Institutes
- Universities
- Quality Control Laboratories
- Industrial Production Facilities
Key Features:
- Equipped with a 5-inch LCD touch panel for intuitive operation and excellent user experience.
- Automatically converts dynamic viscosity to kinematic viscosity by entering the sample density.
- Displays real-time measurement results for continuous monitoring and accurate analysis.
- Supports four selectable viscosity display units to meet different laboratory requirements.
- User-defined measurement range for flexible testing of various liquid samples.
- Final measurement value hold function for convenient recording and data analysis.
- High-precision digital measurement with excellent accuracy and repeatability.
- User-friendly interface designed for quick setup and efficient operation.
- Ideal for measuring the viscosity of chemicals, pharmaceuticals, cosmetics, food products, paints, coatings, and other liquid samples.
- Reliable Japanese quality from AS ONE Corporation, suitable for research, quality control, and industrial laboratories.
Technical Specifications:
| Specification | Details |
|---|---|
| Model | ASJ-8ST |
| Brand | AS ONE Corporation |
| Country of Origin | Japan |
| Viscosity Measurement Range | 1–2,000,000 mPa·s |
| Temperature Measurement Range | 0–100°C |
| Resolution | 1 mPa·s |
| Accuracy | ±1.0% F.S. |
| Repeatability | ±0.5% F.S. |
| Rotation Speeds | 0.3, 0.6, 1.5, 3, 6, 12, 30, 60 rpm |
| Full Scale (F.S.) Torque | 673.7 dyne·cm² |
| Wetted Parts Material | SUS304 Stainless Steel |
| Power Supply | AC 100–240 V (AC Adapter Included) |
| Dimensions (W × D × H) | 285 × 300 × 565 mm (Maximum) |
| Weight | Approx. 5.3 kg (Including Stand) |
Package size: 355 x 400 x 360 mm 8.9 kg
Benefits:
- Accurate and reliable viscosity measurements.
- Easy operation through a modern touch-screen interface.
- Saves time with automatic kinematic viscosity calculation.
- Wide measurement range covers various liquid samples.
- Durable stainless-steel wetted parts for long service life.
- Excellent repeatability for consistent test results.
- Compact design suitable for laboratory environments.
Why Choose ASJ-8ST?
- Advanced 5-inch touch panel operation.
- High measurement accuracy and repeatability.
- Wide viscosity measurement range.
- Automatic kinematic viscosity conversion.
- Multiple spindle speeds for different testing requirements.
- Reliable Japanese quality from AS ONE Corporation.
- User-friendly interface with real-time display.
- Ideal for research, quality control, and industrial laboratories.
Frequently Asked Questions (FAQ):
What is the measurement range of the ASJ-8ST?
The viscometer measures viscosities from 1 to 2,000,000 mPa·s.
Can it calculate kinematic viscosity?
Yes. By entering the sample density, the instrument automatically converts dynamic viscosity to kinematic viscosity.
How many viscosity units are available?
The ASJ-8ST supports four selectable viscosity units.
Does it display results in real time?
Yes. The touch panel continuously displays measurement results during testing.
Is it suitable for pharmaceutical and food laboratories?
Yes. It is widely used in pharmaceutical, food, cosmetic, chemical, research, and quality control laboratories.
Product Link: https://www.axel-gl.com/en/asone/d/4-2877-01/?q=ASJ-8ST
| Weight | 8.9 kg |
|---|---|
| Dimensions | 355 × 400 × 360 mm |
